Type D : Driver HBG Series
Type E : Driver ELG Series
Model : WV61-80
| Power Consumption | 80 W |
| Input Voltage | 100-305 VAC 50/60 Hz. |
| Light Source Flux (Lm) | 12,000 |
| Efficacy | 150lm/W |
| Power Factor | >0.95 |
| Beam Angle | 60° and 90° |
| Work Temperature | -10°C to +65°C |
| Life Time | 50,000 hrs. |
| IP Rating | IP 67 |
| Glare Protection | Yes |
| Optic Material | PMMA |
| LED Light Source | Lumileds 160 pcs. |
| Heat sink | WIP : Aluminium Die Casting |
| Color Rendering Index (CRI) | >80 |
| Color Temperature (TC) | 3,000K/4,000K/5,000K/6,500K |
| Driver | Meanwell, Inventronics |
| Dimension (WxLxH mm.) | 350×123 |
| Heat sinkWeight(Kg.) | 1.80 |
| Driver Weight (Kg.) | 1.18 |
| Griss Weught (Kg.) | 3.52 |
| Warranty | 3 years |
Model : WV61-100
| Power Consumption | 100 W |
| Input Voltage | 100-305 VAC 50/60 Hz. |
| Light Source Flux (Lm) | 15,000 |
| Efficacy | 150lm/W |
| Power Factor | >0.95 |
| Beam Angle | 60° and 90° |
| Work Temperature | -10°C to +65°C |
| Life Time | 50,000 hrs. |
| IP Rating | IP 67 |
| Glare Protection | Yes |
| Optic Material | PMMA |
| LED Light Source | Lumileds 160 pcs. |
| Heat sink | WIP : Aluminium Die Casting |
| Color Rendering Index (CRI) | >80 |
| Color Temperature (TC) | 3,000K/4,000K/5,000K/6,500K |
| Driver | Meanwell, Inventronics |
| Dimension (WxLxH mm.) | 350×123 |
| Heat sinkWeight(Kg.) | 1.80 |
| Driver Weight (Kg.) | 1.18 |
| Griss Weught (Kg.) | 3.52 |
| Warranty | 3 years |
Model : WV61-120
| Power Consumption | 120 W |
| Input Voltage | 100-305 VAC 50/60 Hz. |
| Light Source Flux (Lm) | 18,000 |
| Efficacy | 150lm/W |
| Power Factor | >0.95 |
| Beam Angle | 60° and 90° |
| Work Temperature | -10°C to +65°C |
| Life Time | 50,000 hrs. |
| IP Rating | IP 65 |
| Glare Protection | Yes |
| Optic Material | PMMA |
| LED Light Source | Lumileds 160 pcs. |
| Heat sink | WIP : Aluminium Die Casting |
| Color Rendering Index (CRI) | >80 |
| Color Temperature (TC) | 3,000K/4,000K/5,000K/6,500K |
| Driver | Meanwell, Inventronics |
| Dimension (WxLxH mm.) | 350×123 |
| Heat sinkWeight(Kg.) | 1.80 |
| Driver Weight (Kg.) | 1.18 |
| Griss Weught (Kg.) | 3.52 |
| Warranty | 3 years |
Model : WV61-150
| Power Consumption | 150 W |
| Input Voltage | 100-305 VAC 50/60 Hz. |
| Light Source Flux (Lm) | 18,000 |
| Efficacy | 150lm/W |
| Power Factor | >0.95 |
| Beam Angle | 60° and 90° |
| Work Temperature | -10°C to +65°C |
| Life Time | 50,000 hrs. |
| IP Rating | IP 67 |
| Glare Protection | Yes |
| Optic Material | PMMA |
| LED Light Source | Lumileds 160 pcs. |
| Heat sink | WIP : Aluminium Die Casting |
| Color Rendering Index (CRI) | >80 |
| Color Temperature (TC) | 3,000K/4,000K/5,000K/6,500K |
| Driver | Meanwell, Inventronics |
| Dimension (WxLxH mm.) | 350×123 |
| Heat sinkWeight(Kg.) | 1.80 |
| Driver Weight (Kg.) | 1.18 |
| Griss Weught (Kg.) | 3.52 |
| Warranty | 3 years |
Model : WV61-200
| Power Consumption | 200 W |
| Input Voltage | 100-305 VAC 50/60 Hz. |
| Light Source Flux (Lm) | 30,000 |
| Efficacy | 150lm/W |
| Power Factor | >0.95 |
| Beam Angle | 60° and 90° |
| Work Temperature | -10°C to +65°C |
| Life Time | 50,000 hrs. |
| IP Rating | IP 67 |
| Glare Protection | Yes |
| Optic Material | PMMA |
| LED Light Source | Lumileds 160 pcs. |
| Heat sink | WIP : Aluminium Die Casting |
| Color Rendering Index (CRI) | >80 |
| Color Temperature (TC) | 3,000K/4,000K/5,000K/6,500K |
| Driver | Meanwell, Inventronics |
| Dimension (WxLxH mm.) | 350×123 |
| Heat sinkWeight(Kg.) | 1.80 |
| Driver Weight (Kg.) | 1.18 |
| Griss Weught (Kg.) | 3.52 |
| Warranty | 3 years |
Model : WV61-240
| Power Consumption | 240 W |
| Input Voltage | 100-305 VAC 50/60 Hz. |
| Light Source Flux (Lm) | 36,000 |
| Efficacy | 150lm/W |
| Power Factor | >0.95 |
| Beam Angle | 60° and 90° |
| Work Temperature | -10°C to +65°C |
| Life Time | 50,000 hrs. |
| IP Rating | IP 67 |
| Glare Protection | Yes |
| Optic Material | PMMA |
| LED Light Source | Lumileds 160 pcs. |
| Heat sink | WIP : Aluminium Die Casting |
| Color Rendering Index (CRI) | >80 |
| Color Temperature (TC) | 3,000K/4,000K/5,000K/6,500K |
| Driver | Meanwell, Inventronics |
| Dimension (WxLxH mm.) | 350×123 |
| Heat sinkWeight(Kg.) | 1.80 |
| Driver Weight (Kg.) | 1.18 |
| Griss Weught (Kg.) | 3.52 |
| Warranty | 3 years |
